TG003
-10W-400W
-aluminum housing
-linear driver 200-240v or
DOB wide-range voltage
150-300w 75% wattage
-sensor optional
-IP65
-dimension
10w: 103x84x25mm
20w: 122x95x25mm
30w: 160x123x28mm
50w: 206x160x28mm
100w: 270x210x30mm
150w: 330x250x35mm
200w: 370x270x35mm
300w: 400x310x35mm
IP16
10W-300W
-aluminum housing
-nano or electro-plating
reflector
-non-isolated driver
150-300w 75% wattage
-sensor optional
-IP65
-dimension
10w: 100x80x22mm
20w: 120x93x23mm
30w: 160x120x25mm
50w: 210x160x28mm
100w: 270x210x35mm
150w: 320x230x37mm
200w: 380x280x40mm
300w: 440x330x50mm
IP22
10W-300W
-aluminum housing
-nano reflector
-DOB wide-range voltage
150-300w 75% wattage
-small dimension,economic type
-IP65
-dimension
10w: 85x65x15mm
20w: 100x80x15mm
30w: 130x98x15mm
50w: 155x115x15mm
100w: 200x165x15mm
150w: 240x195x20mm
200w: 275x238x20mm
300w: 318x268x20mm
LED Projector
-dimension
30w: 155x125x25mm50w: 210x160x25mm100w: 270x208x25mm
TGD008
10W-300W
-aluminum housing-nano reflector-linear driver 200-240v orDOB wide-range voltageTGD
-10W-300W
-aluminum housing
-100-265v
-IP65
-dimension
10w: 104x125x28.5mm
30w: 209x168x34mm
50w: 200x237x36.8mm
150w: 335x250x33mm
200w: 380x282x33mm
300w: 455x328x35mm
400w: 485x368x35mm
TG002
-50W-400W
-aluminum housing+nano reflector+optical lens
-isolated driver
-dimension
50w: 200x158x36.1mm100w: 280x220x36.1mm150w: 320x250x38.1mm
200w: 370x280x38.1mm
300w: 410x330x38.6mm
400w: 490x350x38.6mm
100w: 237x303x51mm
150w: 420x333x51mm
200w: 470x385x51mm
300w: 471x429x70mm
TTG041
60W/100W/200W/300W
-aluminum housing
-glass lens
-polycrystalline silicon solar
panel 6v/10w-15w-20w-
25w
-warranty 2 years
-w/ remote control
-lithium iron phosphate battery 3.2v/8AH-12AH-
16AH-20AH
-charging time 4-6hrs
-working time (rainy day) 2-
3 days
-photo control+timer+ radar
sensor
-dimension
60w body:210x165x50
panel:235x350
100w body:255x185x50
panel:350x350
200w body:310x230x50
panel:350x450
300w body:370x265x50
panel:350x530
TTG042
60W/100W/200W/300W
-aluminum housing
-glass lens
-polycrystalline silicon solar
panel 6v/12w-18w-25w-
30w
-warranty 2 years
-w/ remote control
-lithium iron phosphate battery 3.2v/10AH-15AH-
20AH-25AH
-charging time 4-6hrs
-working time (rainy day)
2-3 days
-photo control+timer+ radar
sensor+strobe+5-level
power indicator
-dimension
60w body:195x170x55
panel:350x350
100w body:240x190x55
panel:350x450
200w body:298x240x55
panel:350x530
300w body:371x265x55
panel:350x630
LED solar light
TTG043
60W/100W/200W/300W
-aluminum housing
-glass lens
-polycrystalline silicon solar
panel 6v/12w-18w-25w-
30w
-warranty 2 years
-w/ remote control
-lithium iron phosphate battery 3.2v/10AH-15AH-
20AH-25AH
-charging time 4-6hrs
-working time (rainy day) 2-
3 days
-photo control+timer+ radar
sensor
-dimension
60w body:195x170x55
panel:235x350
100w body:240x191x55
panel:350x450
200w body:298x240x55
panel:350x530
300w body:371x265x55
panel:350x630
5W-200W
DFRX
500W-1500W
DC12V/24V to AC110/220V
GAX
100W-2000W
DC12V/24V to AC110/220V
SCO-A/B
100W-2000W
10A/20A/30A 12V/24V
A
B
Solar Panels
Inverter
Solar Controller
XH-FX
50W/100W/150W/200W
-aluminum housing
-non-isolated or isolated
driver
-full power output
-withstand 1500v,
surge voltage 3500v
-beam angle 70-140°
-optical lens
-warranty 2 years
-dimension
50w: 420x200x70(Φ50)
100w: 495x215x80(Φ60)
150w: 540x215x80(Φ60)
200w: 600x235x80(Φ60)
LD039
50W/100W/150W/200W
-aluminum housing
-linear driver 200-240v or
DOB wide-range voltage
-full power output
-withstand 1500v,
surge voltage 3500v
-beam angle 80-145°
-optical lens
-warranty 2 years
-dimension
50w: 390x160x70(Φ60)
100w: 465x195x70(Φ60)
150w: 525x215x70(Φ60)
200w: 595x245x70(Φ60)
LD030
30W/50W/100W/150W/200W
-aluminum housing
-non-isolated or isolated
driver
-full power output
-withstand 1500v,surge
voltage 4000v for non-
isolated driver;withstand
1500v,surge voltage 4000v
or 6000v for isolated driver
-beam angle 80-145°
-optical lens
-warranty 2 or 3 years
-dimension
30w: 320x135x58(Φ40)
50w: 377x147x68(Φ50)
100w: 500x185x80(Φ60)
150w: 585x210x80(Φ60)
200w: 630x240x85(Φ60)
XH-JZ
50W/100W/150W/200W
-aluminum housing
-DOB wide-range voltage
-full power output
-withstand 1500v,
surge voltage 3500v
-beam angle 60-120°
-optical lens
-warranty 2 years
-dimension
50w: 398x139x50(Φ50)
100w: 525x183x50(Φ60)
150w: 625x188x50(Φ60)
200w: 650x220x50(Φ60)
LD040
50W/100W/150W/200W
-aluminum housing
-linear driver 200-240v or
DOB wide-range voltage
-full power output
-withstand 1500v,
surge voltage 3500v
-beam angle 80-145°
-optical lens
-warranty 2 years
-dimension
50w: 408x138x23(Φ50)
100w: 460x151x23(Φ60)
150w: 537x184x23(Φ60)
200w: 650x211x23(Φ60)
LED Road Light
LED Road Light
LS-LED1214
30W/50W
-aluminum Housing Gray
-size(LxWxH):372x250x150mm
-optional Part: Arm andPhotocontroller
TLD064
100W/150W/200W/250W
-ABS plastic body
-polycrystalline silicon solar
panel 6v/8w-10w-12w-15w
-lithium iron phosphate
battery 3.2v/8AH-10AH-
12AH-16AH
-charging time 4-6hrs
-working time (rainy day)
1-2days
-warranty 2 years
-timer or radar sensor
-w/ remote control
-50cm arm optional
-dimension
100w body:450x248x63
panel:208x335
150w body:530x248x63
panel:208x414
200w body:608x260x65
panel:208x490
250w body:686x268x65
panel:207x567
TLD066
200W/300W/400W
-ABS plastic body
-polycrystalline silicon solar
panel 6v/18w-22w-28w
-lithium iron phosphate
battery 3.2v/15AH-20AH-
25AH
-charging time 6-8hrs
-working time (rainy day)
2-3days
-warranty 3 years
-timer or radar sensor
-w/ remote control
-50cm arm optional
-dimension
200w body:620x280x90
panel:435x273
300w body:710x280x93
panel:553x273
400w body:820x280x90
panel:653x273
-withstand 1500v,surge
voltage 4000v or 6000v
-beam angle 80-145°
-optical lens
-warranty 2 or 3 years
-dimension
50w: 370x153x62(Φ60)
100w: 467x183x72(Φ60)
150w: 582x213x72(Φ60)
200w: 645x233x72(Φ60)
300w: 710x263x72(Φ60)
LD050
50W/100W/150W/200W/300W
-aluminum housing
-non-isolated or isolated driver
-Straight arm/Swivel arm
-full power output
LD041
50W/100W/150W/200W
-aluminum housing
-non-isolated or isolated
driver
-full power output
-withstand 1500v,surge
voltage 4000v or 6000v
-beam angle 80-145°
-optical lens
-warranty 2 or 3 years
-dimension
50w: 400x182x71(Φ60)
100w: 490x216x71(Φ60)
150w: 590x249x71(Φ60)
200w: 660x262x71(Φ60)
LED Solar Road Light
UFO LED High Bay Light
FD023
100W/150W/200W
-aluminum housing
-linear driver 200-240v or
DOB wide-range voltage
-with spot-type optical lens
-full wattage output
-withstand 1500v,surge
voltage 3500v
-warranty 2 years
-dimension
100w: Φ270x55mm
150w: Φ310x55mm
200w: Φ380x55mm
FD021
100W/150W/200W
-aluminum housing
-non-isolated driver or
isolated driver
-with spot-type optical lens -full wattage output
-withstand 1500v,surge
voltage 4000v
-warranty 2 years
-dimension
100w: Φ270x96mm
150w: Φ310x96mm
200w: Φ380x96mm
ZGC-150
150W
-aluminum housing
-non-isolated driver or
isolated driver
-full wattage output
-warranty 2 years
-IP65
-dimension
150w: Φ250x131.6mm
TG017B
100W/200W/300W/400W/500W/600W/800W/1000W
-aluminum housing
-non-isolated or isolated driver
-withstand 1500v
-full power output
-warranty 2/3/5 years
-dimension
100W: 410x98x45mm
200W: 410x220x45mm
300W: 410x312x45mm
400W: 410x410x45mm
500W: 410x508x45mm
600W: 760x312x45mm
800W: 760x410x45mm
1000W: 760x508x45mm
CDTGD
50W
-Rechargeable
-aluminum housing
-dimension 293x232x134mm
FD024
100W/150W/200W
-aluminum housing
-linear driver 200-240v or
DOB wide-range voltage
-with spot-type optical lens
-full wattage output
-withstand 1500v,surge
voltage 3500v
-warranty 2 years
-dimension
100w: Φ263x26mm
150w: Φ305x28mm
200w: Φ335x32mm
LED Rechargeable Floodlight
GKD-150
150W
-aluminum housing
-non-isolated driver or
isolated driver
-full wattage output
-warranty 2 years
-IP65
LED Suspended Down Llight
LED Projector
