Lifting and Lashing Solution!
CONTENTS
ABOUT US
Anji Deheng Rigging Co., ltd specializes in researching, designing, manufacturing and exporting various products of lifting rigging and cargo control. With over ten years' combined experience, we can supply flat webbing sling, round sling, endless one way sling, ratchet tie down, ratchet strap, winch strap, tow strap, E track system, load binder, chains, hoists, shackles and other relevant rigging hardware. Based on strict quality control, competitive price and excellent service, our products are popular in Germany, Spain, Italy, UK, the United States, Canada, Poland, Brazil, Australia, Japan and so on. We always look forward to establishing business relationships with new customers all over the world.
欧标捆绑带
Ratchet Tie Down
14
汽车捆绑带
Car Lashing Strap
30
平板车配件
Flatbed Truck Accessories
34
箱式货车配件
Enclosed Trailer Accessories
42
美标捆绑带
US Ratchet Strap
22
美标卷扬带
US Winch Strap
27
欧标链条和拉紧器
EN Chain & Binder
48
G80 链式吊索
G80 Chain Sling
50
欧标圆套
Round Sling
10
欧标吊带
Webbing Sling
06
捆绑带精包装
Plastic Hang Rack
20
G80 链式吊索
G80 Chain Sling
50
Webbing sling
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
WLL 2T
Working Load Limit:1t
Webbing Width:30mm
Webbing Color:Purple
Lenth:1m-12m
Safefy Factor:Standard 7:1 optiona 5:1,6:1;8:1
Material:100% Polyester
Standard:EN 1492-1
Certificate:TUV/GS
WLL 3T
WLL 1T
Working Load Limit:1t
Webbing Width:30mm
Webbing Color:Purple
Lenth:1m-12m
Safefy Factor:Standard 7:1 optiona 5:1,6:1;8:1
Material:100% Polyester
Standard:EN 1492-1
Certificate:TUV/GS
Working Load Limit:1t
Webbing Width:30mm
Webbing Color:Purple
Lenth:1m-12m
Safefy Factor:Standard 7:1 optiona 5:1,6:1;8:1
Material:100% Polyester
Standard:EN 1492-1
Certificate:TUV/GS
|
Working Load Limit
|
1t |
| Width | 30mm |
| Length | 1m-12m |
| Color | Purple |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
2t |
| Width | 60mm |
| Length | 1m-12m |
| Color | Green |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
3t |
| Width | 90mm |
| Length | 1m-12m |
| Color | Yellow |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
WLL 5T
WLL 6T
WLL 4T
WLL 10T
WLL 12T
WLL 8T
|
Working Load Limit
|
4t |
| Width | 120mm |
| Length | 1m-12m |
| Color | Grey |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
6t |
| Width | 180mm |
| Length | 1m-12m |
| Color | Brown |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
5t |
| Width | 150mm |
| Length | 1m-12m |
| Color | Red |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
8t |
| Width | 240mm |
| Length | 1m-12m |
| Color | Blue |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
10t |
| Width | 300mm |
| Length | 1m-12m |
| Color | Orange |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
12t |
| Width | 300mm |
| Length | 1m-12m |
| Color | Orange |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
欧标圆套
ROUND sling
Endless Round Sing is constructed from a continuous loop of 100% polyester fiber. Each round sling is covered by a seamless, tubular protective sleeve to protect the load-bearing fibers from damage. Because it is soft and flexible, it enables the user to rotate hook and load contact points, resulting in increased sling longevity. It has been widely used in shipping building, mining, petroleum, ports and other areas.
无尽的圆形吊带是由100%聚酯纤维的连续环路构成的。每条圆形吊带都由一个无缝的管状保护套覆盖，以保护承重纤维免受损坏。由于它柔软而灵活，它使用户能够旋转吊钩和负载接触点，从而增加吊带的使用寿命。它已被广泛用于航运建筑、采矿、石油、港口和其他领域。
WLL 2T
WLL 3T
WLL 1T
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
|
Working Load Limit
|
1t |
| Width | 50mm |
| Length | 1m-12m |
| Color | Purple |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
2t |
| Width | 55mm |
| Length | 1m-12m |
| Color | Green |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
3t |
| Width | 60mm |
| Length | 1m-12m |
| Color | Yellow |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
WLL 5T
WLL 6T
WLL 4T
WLL 10T
WLL 12T
WLL 8T
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
|
Working Load Limit
|
4t |
| Width | 65mm |
| Length | 1m-12m |
| Color | Grey |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
5t |
| Width | 70mm |
| Length | 1m-12m |
| Color | Red |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
6t |
| Width | 75mm |
| Length | 1m-12m |
| Color | Brown |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
8t |
| Width | 85mm |
| Length | 1m-12m |
| Color | Blue |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
10t |
| Width | 100mm |
| Length | 1m-12m |
| Color | Orange |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
|
Working Load Limit
|
12t |
| Width | 110mm |
| Length | 1m-12m |
| Color | Orange |
| Safety Factor | Standard 7:1optional:5:1;6:1;8:1 |
| Certificate | TUV/GS/CE |
欧标捆绑带
Ratchet tie down
Ratchet Tie Down Strap is a fastener used to hold down your cargo or equipment during transport. It comes with heavy duty polyester webbing and hardware accessories like ratchet buckle and hooks. Usually, we introduce 2 parts ratchet tie down strap, which includes one short/fixed end and one long/loose end. Besides, we also offer endless ratchet tie down strap, which just includes one ratchet buckle and one long webbing.
捆绑带是一种用于在运输过程中压住货物或设备的紧固件。它配有重型聚酯织带和硬件配件，如拉紧器和钩子。通常情况下，该捆绑带包括两部分，一个短/固定端和一个长/松动端。此外，我们还提供环形捆绑带，其中只包括一个拉紧器和一条长织带。
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
25mm*LC0.75t/BS1.5t
35mm*LC1t/BS2t
25mm*LC0.4t/BS0.8t
|
Width
|
25mm |
| Breaking Strength(BS) | 0.8t |
| lashing Capacity(LC) | 0.4t |
| Length | 3m-15m |
| Ratchet Buckle | Various |
| End fitting | Double J hook |
| Safety Factor | 2:1 |
| Certificate | TUV/GS |
|
Width
|
25mm |
| Breaking Strength(BS) | 1.5t |
| lashing Capacity(LC) | 0.75t |
| Length | 3m-15m |
| Ratchet Buckle | Various |
| End Fitting | Double J hook |
| Safety Factor | 2:1 |
| Certificate | TUV/GS |
|
Width
|
35mm |
| Breaking Strength(BS) | 2t |
| lashing Capacity(LC) | 1t |
| Length | 3m-15m |
| Ratchet Buckle | Various |
| End Fitting | Double J hook |
| Safety Factor | 2:1 |
| Certificate | TUV/GS |
www.dhrigging.com sales@dhrigging.com +86 13738031292
50mm*LC2.5t/BS5t for Australia
50mm*LC2.5t/BS5t ERGO
|
Width
|
50mm |
| Breaking Strength(BS) | 5t |
| lashing Capacity(LC) | 2.5t |
| Length | 3m-15m |
| Ratchet Buckle | ergo |
| End Fitting | Double J hook |
| Safety Factor | 2:1 |
| Certificate | TUV/GS |
|
Width
|
50mm |
| Breaking Strength(BS) | 5t |
| lashing Capacity(LC) | 2.5t |
| Length | 3m-15m |
| Ratchet Buckle | Various |
| End Fitting | Swan hook |
| Safety Factor | 2:1 |
| Certificate | TUV/GS |
www.dhrigging.com sales@dhrigging.com +86 13738031292
50mm*LC1.5t/BS3t
50mm*LC2.5t/BS5t
35mm*LC1.5t/BS3t
|
Width
|
35mm |
| Breaking Strength(BS) | 3t |
| lashing Capacity(LC) | 1.5t |
| Length | 3m-15m |
| Ratchet Buckle | Various |
| End Fitting | Double J hook |
| Safety Factor | 2:1 |
| Certificate | TUV/GS |
|
Width
|
50mm |
| Breaking Strength(BS) | 3t |
| lashing Capacity(LC) | 1.5t |
| Length | 3m-15m |
| Ratchet Buckle | Various |
| End Fitting | Double J hook |
| Safety Factor | 2:1 |
| Certificate | TUV/GS |
|
Width
|
50mm |
| Breaking Strength(BS) | 5t |
| lashing Capacity(LC) | 2.5t |
| Length | 3m-15m |
| Ratchet Buckle | Various |
| End Fitting | Double J hook |
| Safety Factor | 2:1 |
| Certificate | TUV/GS |
50mm*LC2.5t/BS5t for Australia
|
Width
|
50mm |
| Breaking Strength(BS) | 5t |
| lashing Capacity(LC) | 2.5t |
| Length | 3m-15m |
| Ratchet Buckle | Various |
| End Fitting | Swan hook |
| Safety Factor | 2:1 |
| Certificate | TUV/GS |
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
100mm*LC5t/BS10t
75mm*LC5t/BS10t
|
Width
|
75mm |
| Breaking Strength(BS) | 10t |
| lashing Capacity(LC) | 5t |
| Length | 3m-15m |
| Ratchet Buckle | Various |
| End Fitting | Double J hook |
| Safety Factor | 2:1 |
| Certificate | TUV/GS |
|
Width
|
100mm |
| Breaking Strength(BS) | 10t |
| lashing Capacity(LC) | 5t |
| Length | 3m-15m |
| Ratchet Buckle | Various |
| End Fitting | Double J hook |
| Safety Factor | 2:1 |
| Certificate | TUV/GS |
25mm 2PK 25mm 2PK 25mm 2PK
25mm 4PK 25mm 4PK 25mm 4PK
50mm 1PK 50mm 1PK 50mm 1PK
Ratchet Tie Down Strap can be packed into plastic hang rack. DHR offer Tie Down Set in 1PK, 2PK and 4PK. With this packaging, you can hang the ratchet tie down on your shelf. This kind of value pack is suitable for retail in supermarket, hardware stores, tool stores.
我们提供1PK、2PK和4PK的扎带套装。有了这种精美包装，你可以把捆绑带挂在你的货架上。这种包装适用于超市、五金店、工具店的零售。
精包装
Plastic hang rack
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
美标捆绑带
Us ratchet strap
1" Ratchet Strap
|
Width
|
1" |
| Assembly Break Strength | 1500lbs |
| Working Load Limit(WLL) | 500lbs |
| Length | 15' or customized |
| webbing Color | yellow |
| End Fitting | wire hook, s hook |
| Ratchet Buckle | iron handle |
| Standard | WSTDA-T-1 |
| Label | White Non-woven label |
2" E Track Logistic Strap
|
Width
|
2" |
| Assembly Break Strength | 4400lbs |
| Working Load Limit(WLL) | 1466lbs |
| Length | 12' , 16' , 20' , Or Customized |
| webbing Color | yellow |
| End Fitting | E track hook |
| Ratchet Buckle | Short iron Handle |
| Standard | WSTDA-T-1 |
| Label | White Non-woven label |
W/ Wire Hook W/ S Hook
W/ E Track Hook
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
2" Ratchet Strap
|
Width
|
2" |
| Assembly Break Strength | 10000lbs |
| Working Load Limit(WLL) | 3333lbs |
| Length | 27' or customized |
| webbing Color | yellow |
| End Fitting | wire hook, Flat hook, D-ring, chain anchor |
| Ratchet Buckle | aluminum handle |
| Standard | WSTDA-T-1 |
| Label | White Non-woven label |
|
Width
|
3" |
| Assembly Break Strength | 16200lbs |
| Working Load Limit(WLL) | 5400lbs |
| Length | 30' Or Customized |
| webbing Color | yellow |
| End Fitting | Wire Hook, Flat Hook, D-Ring, Chain Anchor |
| Ratchet Buckle | Aluminum Handle |
| Standard | WSTDA-T-1 |
| Label | White Non-woven label |
3" Ratchet Strap
W/ Wire Hook W/ Flat Hook
W/ D-Ring W/ Chain Anchor
W/ Wire Hook W/ Flat Hook
W/ D-Ring W/ Chain Anchor
4" Ratchet Strap
|
Width
|
4" |
| Assembly Break Strength | 16200lbs |
| Working Load Limit(WLL) | 5400lbs |
| Length | 30' or customized |
| webbing Color | yellow |
| End Fitting | wire hook, Flat hook, D-ring, chain anchor |
| Ratchet Buckle | aluminum handle |
| Standard | WSTDA-T-1 |
| Label | White Non-woven label |
美标卷扬带
Us winch strap
2" Winch Strap
|
Width
|
2" |
| Assembly Break Strength | 10000lbs |
| Working Load Limit(WLL) | 3333lbs |
| Length | 30' or customized |
| webbing Color | yellow |
| End Fitting | Wire Hook, Flat Hook, D-Ring, Chain Anchor |
| Standard | WSTDA-T-1 |
| Label | White Non-woven label |
W/ Wire Hook W/ Flat Hook
W/ Wire Hook W/ Flat Hook
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
3" Winch Strap
|
Width
|
3" |
| Assembly Break Strength | 16200lbs |
| Working Load Limit(WLL) | 5400lbs |
| Length | 30' or customized |
| webbing Color | yellow |
| End Fitting | Wire Hook, Flat Hook, D-Ring, Chain Anchor |
| Standard | WSTDA-T-1 |
| Label | White Non-woven label |
W/ Wire Hook W/ Flat Hook
4" Winch Strap
|
Width
|
4" |
| Assembly Break Strength | 16200lbs |
| Working Load Limit(WLL) | 5400lbs |
| Length | 30' or customized |
| webbing Color | yellow |
| End Fitting | Wire Hook, Flat Hook, D-Ring, Chain Anchor |
| Standard | WSTDA-T-1 |
| Label | White Non-woven label |
W/ Wire Hook W/ Flat Hook
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
汽车绑带
Car lashing strap
When you transport Auto on a long vehicle or haul a car on your trailer, the most important thing is to ensure the auto safety during the transportation. We offer a lot of different car lashing straps. And we have been designing new straps according to different application.
当你用卡车运输汽车或用拖车拖拽汽车时，最重要的是确保运输过程中的汽车安全。我们提供很多不同的汽车绑带。而且我们一直在根据不同的应用设计新的绑带。
1
2
3
4
5
6
7
8
9
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
13
14
15
16
17
18
10
11
12
22
23
24
19
20
21
平板车配件
flatbed truck accessories
Flatbed trucks must ensure safe loading. As a cargo control products provider, Anji Deheng Rigging Co.,Ltd can offer all the flatbed securement equipments you need.
平板车必须确保安全装载。作为货物控制产品供应商，安吉德亨索具有限公司可以提供您所需要的所有平板车固定设备。
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
| NO. | Size | W.L.L. | B.S. | Length | Finish | End Fitting |
| 1 | 1/4'' | 3,150lbs | 12,600lbs | 16', 20', 25' | Yellow Zinc | Clevis Grab Hook |
| 2 | 5/16'' | 4,700lbs | 18,800lbs | 16', 20', 25' | Yellow Zinc | Clevis Grab Hook |
| 3 | 3/8'' | 6,600lbs | 26,400lbs | 16', 20', 25' | Yellow Zinc | Clevis Grab Hook |
| 4 | 1/2'' | 11,300lbs | 45,200lbs | 16', 20', 25' | Yellow Zinc | Clevis Grab Hook |
| 5 | 5/8'' | 15,800lbs | 63,200lbs | 16', 20', 25' | Yellow Zinc | Clevis Grab Hook |
Grade 70 Transport Chain
G70 chain is heat-treated and strength tested.
Meet requirements by DOT,CCMTA & CVSA for truck tie-down use.
***NOT TO BE USED FOR OVERHEAD LIFTING! DO NOT EXCEED CAPACITY!***
G70链条经过热处理和强度测试。
符合DOT、CCMTA和CVSA对卡车捆绑使用的要求。
***不能用于高空吊装! 请勿超过额定负荷拉力！***
| NO. | Chain Size(use with) | W.L.L. | B.S. | Color | End Fitting |
| 1 | 1/4'' G70 | 3,150lbs | 11,000lbs | Red | Grab Hook |
| 2 | 5/16" G70 - 3/8" G43 | 5,400lbs | 19,000lbs | Red | Grab Hook |
| 3 | 5/16" G70 - 3/8" G70 | 6,600lbs | 26,400lbs | Red | Grab Hook |
| 4 | 3/8" G70 - 1/2" G43 | 9,200lbs | 33,000lbs | Red | Grab Hook |
| 5 | 1/2" G70 - 5/8" G43 | 13,000lbs | 46,000lbs | Red | Grab Hook |
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
Meet FMCSA requirements and WSTDA T-6 standards.
| NO. | Chain Size(use with) | W.L.L. | B.S. | Color | End Fitting |
| 1 | 1/4'' G70 | 3,150lbs | 11,000lbs | Red | Grab Hook |
| 2 | 5/16" G70 - 3/8" G43 | 5,400lbs | 19,000lbs | Red | Grab Hook |
| 3 | 5/16" G70 - 3/8" G70 | 6,600lbs | 26,400lbs | Red | Grab Hook |
| 4 | 3/8" G70 - 1/2" G43 | 9,200lbs | 33,000lbs | Red | Grab Hook |
| 5 | 1/2" G70 - 5/8" G43 | 13,000lbs | 46,000lbs | Red | Grab Hook |
Lever Load Binder
杠杆式拉紧器
Ratchet Load Binder棘轮式拉紧器
4'' Weld-on Winch (standard)
4'' Portable Bolt-on Winch (standard)
2"Lashing Winch
|
Width
|
2" |
| Work load limt | 3,333lbs |
| beaking strength | 10,000lbs |
| mount type | Weld-On, Bolt-On |
|
Width
|
4" |
| Work load limt | 5,500lbs |
| beaking strength | 16,500lbs |
| mount type | Weld-On |
|
Width
|
4" |
| Work load limt | 5,500lbs |
| beaking strength | 16,500lbs |
| mount type | Bolt-on, 2 bolts included. |
4'' Double L Track Sliding Winch
(standard)
Winch Bar
4'' Notched Sliding Winch (standard)
|
Width
|
4" |
| Work load limt | 3,333lbs |
| beaking strength | 10,000lbs |
| mount type | Sliding, Bolt-On |
|
Width
|
4" |
| Work load limt | 5,500lbs |
| beaking strength | 16,500lbs |
| mount type | Sliding |
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
Winch Strap
Weld-on D Ring
Winch Track
|
material
|
steelaluminum |
| thickness | 1/4'' |
| length | 6ft |
|
Width
|
2", 3", 4" |
| Length | 30' or customized |
| W.L.L. | 3,333lbs/5,400lbs |
| M.B.S | 10,000lbs/16,200lbs |
| end Fitting | Flat Hook Wire Hook Chain Anchor D-Ring |
1
2
1
Black Painted
40" Combination Type
2
Chrome
36" Strandard Type
1/2'' M.B.S. 12,000lbs
5/8'' M.B.S. 18,000lbs
3/4'' M.B.S. 26,500lbs
1'' M.B.S. 47,000lbs
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
Rubber Tarp Strap
4" Corner Protector
Lumber Tarp
1
2
16' x 28' (4' Drop & Flap) - 14 Oz. Black Tarp
20' x 28' (6' Drop & Flap) - 14 oz. Black Tarp
24' x 28' (8' Drop & Flap) - 14 oz. Black Tarp
Length: 21”
Length: 31”
Strap Winder
Metal Corner Protector
Strap Winder
Coil Rack
8" Corner Protector
1"Corner Protector
厢式货车配件
Enclosed trailer accessories
When you want to ensure the cargo safety in your interior van, we have what you need.
当你想确保你的厢式货车的货物安全时，我们有你需要的东西。
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
E Track Rail
Width: 2''
Length: 5', 8'
Gray Painted
Black Painted
Galvanized
Horizontal Type
Vertival Type
Single Track
Wheel Chock
E Track Hook
E Track Hook with O Ring
www.dhrigging.com sales@dhrigging.com +86 13738031292
E Track Strap
E Track Rope Tie Off
D Ring
www.dhrigging.com sales@dhrigging.com +86 13738031292
E Track with J hook
Wood Beam Socket
Cargo Bar
E Track Load bar/Decking Beam
a. 91''-102'', Aluminum, WLL2,000lbs
b. 91''-102'', Aluminum, WLL3,000lbs
c. 91''-102'', Steel, WLL3,000lbs
1/2'' M.B.S. 12,000lbs
5/8'' M.B.S. 18,000lbs
3/4'' M.B.S. 26,500lbs
1'' M.B.S. 47,000lbs
Steel/Aluminum Round Tube with Spring, 2'' x 4'' plastic footpad
Jack Bar
a. Insered Square Tube Size: 1.5'' x 1.5'' Length: 86'' - 104''/107''/109''/115''
b. Welded Square Tube Size: 1.5'' x 1.5'' Length: 86'' - 104''/107''/109''/115''/119''
c. Welded Round Tube Diameter: 1.65'' Length: 86'' - 104''/107''/109''/115''
Cargo Plank
a. Casting fitting Size: 30 x 120mm Length: 2400mm-2700mm
b. Stamping fitting Size: 30 x 125mm
c. Steel Square Tube Size: 40 x 40 mm Length: 1960mm-2910mm
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
L Track System
L Track Rail
Single Stud Fitting
Double Stud Fitting
欧标链条和拉紧器
EN Chain & Binder
www.dhrigging.com sales@dhrigging.com +86 13738031292
www.dhrigging.com sales@dhrigging.com +86 13738031292
Chain (Without End Fitting) |
Transport Chain with Hooks |
||||||||
| NO. | Chain Size | Work Load Limit | Proof Load | Breaking Load | Lashing Capacity(LC) | ||||
| mm | daN/KG | Kn | daN/KG | Kn | daN/KG | Kn | daN/KG | Kn | |
| 1 | 6 | 1,120 | 11.2 | 2,830 |
28.3 | 4,520 | 45.2 | 2200 | 22 |
| 2 | 8 | 2,000 | 20.0 | 5,030 | 50.3 | 8,040 | 80.4 | 4000 | 40 |
| 3 | 10 | 3,150 | 31.5 | 7,850 | 78.5 | 12,600 | 126.0 | 6300 | 63 |
| 4 | 13 | 5,300 | 53.0 | 13,300 | 133.0 | 21,200 | 212.0 | 10000 | 100 |
| 5 | 16 | 8,000 | 80.0 | 20,100 | 201.0 | 32,200 | 322.0 | 16000 | 160 |
Breaking Load (B.L.) = 4 x Work Load Limit (W.L.L.) |
B.S. = 2 x L.C. |
||||||||
G80 Ratchet Load Binder
| NO. | Chain Size | L.C. | B.S. | Color | End Fitting |
| 1 | 6mm | 22Kn | 44Kn | Red | Grab Hook with Pin |
| 2 | 8mm | 40Kn | 80Kn | Red | Grab Hook with Pin |
| 3 | 10mm | 63Kn | 126Kn | Red | Grab Hook with Pin |
| 4 | 13mm | 100Kn | 200Kn | Red | Grab Hook with Pin |
| 5 | 16mm | 160Kn |
320Kn | Red | Grab Hook with Pin |
G80 Ratchet Load Binder without Hooks
| NO. | Chain Size | L.C. | B.S. | Color | End Fitting |
| 1 | 6mm | 22Kn | 44Kn | Red | No Hook |
| 2 | 8mm | 40Kn | 80Kn | Red | No Hook |
| 3 | 10mm | 63Kn | 126Kn | Red | No Hook |
| 4 | 13mm | 100Kn | 200Kn | Red | No Hook |
| 5 | 16mm | 160Kn |
320Kn | Red | No Hook |
EN12195-3 Standard; STF=3000daN; Powder Coated Finish; Alloy Steel.
Breaking Strength (B.S.) = 2 x Lashing Capacity (L.C.)
EN12195-3 Standard; STF=3000daN; Powder Coated Finish; Alloy Steel.
Breaking Strength (B.S.) = 2 x Lashing Capacity (L.C.)
G80链条吊索
G80 Chain Sling
| NO. | Types | ||||||
| Single Leg | Chain | Master Link | Connecting link | Clevis Hook with Latch | Assembly | ||
Factor = 1.0 |
Size | W.L.L. | W.L.L. | W.L.L. | W.L.L. | W.L.L. | |
| 1 | 6mm | 1.12t | 1.6t | 1.12t | 1.12t | 1.12t | |
| 2 | 7mm | 1.5t | 1.6t | 1.5t | 2t | 1.5t | |
| 3 | 8mm | 2t | 2.12t | 2t | 2t | 2t | |
| 4 | 10mm | 3.15t | 3.15t | 3.15t | 3.15t | 3.15t | |
| 5 | 13mm | 5.3t | 5.3t | 5.3t | 5.3t | 5.3t | |
| 6 | 16mm | 8t | 8t | 8t | 8t | 8t | |
| Two Leg | Chain | Master Link | Connecting link | Clevis Hook with Latch | Assembly | ||
| Factor = 1.4 | Size | W.L.L. | W.L.L. | W.L.L. | W.L.L. | W.L.L. | |
| 7 | 6mm | 1.12t | 1.6t | 1.12t | 1.12t | 1.568t | |
| 8 | 7mm | 1.5t | 2.12t | 1.5t | 2t | 2.1t | |
| 9 | 8mm | 2t | 3.15t | 2t | 2t | 2.8t | |
| 10 | 10mm | 3.15t | 5.3t | 3.15t | 3.15t | 4.4t | |
| 11 | 13mm | 5.3t | 8t | 5.3t | 5.3t | 7.4t | |
| 12 | 16mm | 8t | 11.2t | 8t | 8t | 11.2t | |
| NO. | Types | ||||||
| Three Leg | Chain | Master Link | Connecting link | Clevis Hook with Latch | Assembly | ||
Factor = 2.1 |
Size | W.L.L. | W.L.L. | W.L.L. | W.L.L. | W.L.L. | |
| 1 | 6mm | 1.12t | 2.36t | 1.12t | 1.12t | 2.36t | |
| 2 | 7mm | 1.5t | 3.15t | 1.5t | 2t | 3.15t | |
| 3 | 8mm | 2t | 4.25t | 2t | 2t | 4.25t | |
| 4 | 10mm | 3.15t | 6.7t | 3.15t | 3.15t | 6.7t | |
| 5 | 13mm | 5.3t | 11.2t | 5.3t | 5.3t | 11.2t | |
| 6 | 16mm | 8t | 17t | 8t | 8t | 16.8t | |
| Four Leg | Chain | Master Link | Connecting link | Clevis Hook with Latch | Assembly | ||
| Factor = 2.1 | Size | W.L.L. | W.L.L. | W.L.L. | W.L.L. | W.L.L. | |
| 7 | 6mm | 1.12t | 2.36t | 1.12t | 1.12t | 2.36t | |
| 8 | 7mm | 1.5t | 3.15t | 1.5t | 2t | 3.15t | |
| 9 | 8mm | 2t | 4.25t | 2t | 2t | 4.25t | |
| 10 | 10mm | 3.15t | 6.7t | 3.15t | 3.15t | 6.7t | |
| 11 | 13mm | 5.3t | 11.2t | 5.3t | 5.3t | 11.2t | |
| 12 | 16mm | 8t | 17t | 8t | 8t | 16.8t | |
Anji Deheng Rigging Co., ltd.
Address:20 / F, Block A, Chamber Of Commerce Building, 99 Tianhuangping South Road, Changshuo Street
Tel/wechat/whatsapp:+86 13738031292
Email: sales@dhrigging.com
Website:www.dhrigging.com
安吉德亨索具有限公司
地址：浙江省安吉县商会大厦A座20楼
电话：+86 13738031292
邮箱：sales@dhrigging.com
网站：www.dhrigging.com
增值电信业务经营许可证：陕B2-20210327 |
陕公网安备 61102302611033号
